Batched Generation in LLM Serving: How Request Scheduling Impacts Outputs

When you ask an LLM a question, it doesn’t just spit out an answer instantly. Behind the scenes, it’s doing millions of calculations-step by step, token by token. Now imagine doing that for 100 people at once. That’s where batched generation comes in. It’s not just about speed. It’s about making sure your GPU isn’t sitting idle while waiting for one slow request to finish. And the secret sauce? How those requests are scheduled.

Why Batching Matters More Than You Think

Early LLM deployments treated each request like a solo runner on a track. One person starts, finishes their lap, then the next goes. Simple. But terribly inefficient. GPUs can handle dozens of sequences at once-but only if you let them. Static batching tried to fix this by grouping requests together before running them. But if one request had a 500-word prompt and another had 10 words, the whole batch had to wait for the long one. That meant up to 60% of your GPU power was wasted.

Enter continuous batching. This isn’t just batching-it’s dynamic, real-time reshuffling. Think of it like a toll booth where cars don’t all line up at once. Instead, as soon as one car passes through, another slips in from the back of the line. No waiting. No empty lanes. That’s what modern systems like vLLM and TensorRT-LLM do. They keep the GPU busy 90% of the time instead of 40%.

How Continuous Batching Actually Works

Here’s the trick: instead of batching entire requests upfront, the system processes them token by token. Each time a model generates a new word, it checks: Who’s done? Who’s still going? Can I slot in a new request? This happens every few milliseconds.

The vLLM framework uses two hard limits to control this:

• max_num_seqs: Max 256 sequences per batch (that’s 256 different conversations running at once)
• max_num_batched_tokens: Max 4,096 total tokens across all sequences

If your batch hits 4,096 tokens, it stops adding new requests-even if it hasn’t hit 256 sequences. If a request finishes early, its memory gets freed up instantly, and a new one jumps in. That’s why you can’t predict exact latency for a single request. It’s not fixed. It’s fluid.

The Memory Problem: KV Cache Fragmentation

Every time an LLM generates text, it remembers what it’s seen so far in something called the Key-Value (KV) cache. In old systems, this cache was stored as one big block per request. If a request needed 1,200 tokens, it got 1,200 tokens of memory-even if it only used 800. The rest sat there, unused. That’s called fragmentation. And it killed efficiency.

PagedAttention changed that. Inspired by how operating systems manage virtual memory, it splits the KV cache into 16KB blocks. These blocks can be scattered across memory like puzzle pieces. When a request finishes part of its generation, only those specific blocks are freed. No wasted space. UCSD research showed this cuts memory fragmentation by up to 70%. That means you can run 2x more requests on the same GPU.

Scheduling Algorithms: It’s Not Just FIFO

Not all batching is created equal. The simplest method is FIFO-first in, first out. But that ignores a huge variable: how long each request will take to generate. A short prompt might finish in 0.3 seconds. A long one might take 4 seconds. If you put them in the same batch, the short ones get stuck.

Length-aware scheduling tries to fix this by grouping similar-length prompts. Better, but still flawed. It doesn’t predict how long the output will be. Two users might type the same prompt, but one asks for a 50-word summary. The other asks for a 500-word essay. Same input. Totally different output length.

That’s where learning-to-rank scheduling comes in. Researchers at UCSD trained a small model to predict generation length based on:

• Input prompt length
• Application type (customer service vs. creative writing)
• Semantic features of the text

The result? 23.7% higher throughput than FIFO. And 15.3% better than length-aware. It doesn’t just guess-it learns from real-world data. You need about 10,000 real request pairs to train it, which takes 4-6 hours of live traffic. But once trained, it’s worth it.

Advanced Systems: Magnus and SLAI

Some systems go even further. Magnus, introduced in mid-2024, uses four components working together:

• A generator length predictor
• An adaptive batcher
• A serving time estimator
• A smart scheduler using HRRN (Highest Response Ratio Next)

It doesn’t just batch-it chooses which requests to insert based on how long they’ve waited and how long they’re expected to take. In tests, it cut average latency by 22.8% compared to standard continuous batching.

Then there’s SLAI (SLO-Aware LLM Inference). This one prioritizes requests that are about to miss their deadline. If a customer service bot has a 2-second SLA, and a request is already at 1.8 seconds, SLAI gives it priority over newer, slower requests. That cuts 99th percentile latency by 34%. For user-facing apps, that’s the difference between “fast” and “frustrating.”

What Developers Actually Experience

On paper, continuous batching sounds perfect. In practice? It’s a black box.

Many developers using vLLM report confusion. One user on the vLLM forum wrote: “I send 1,000 prompts in one call. It batches them automatically. But when I check latency, it’s all over the place. Why is one request taking 5 seconds when others are under 1?”

That’s because the scheduler is constantly adjusting. You don’t control the batch. The system does. And that’s intentional. But it makes debugging hard. If your app has inconsistent response times, it’s not a bug-it’s how the scheduler is working.

The fix? Don’t send requests one at a time. Always batch them in groups. Send 10, 50, or 100 at once. Let the system do its job. And tune your max_num_batched_tokens setting. Too low? You’re not using the GPU well. Too high? You crash with OOM (out-of-memory) errors.

What You Should Do Right Now

If you’re running LLMs in production, here’s your action plan:

1. Use vLLM or TensorRT-LLM-they’re the most mature open-source options.
2. Set max_num_seqs to 256 and max_num_batched_tokens to 4096 as a starting point.
3. Monitor your GPU utilization. If it’s below 70%, you’re underutilizing. If it’s above 90% and you’re seeing timeouts, you’re overloading.
4. Collect real request data for 6 hours. Use it to train a simple length predictor if you’re handling diverse use cases.
5. Set a starvation threshold-if a request waits longer than 500ms, bump its priority. Prevents slow requests from getting stuck forever.

The Bigger Picture

By 2026, 90% of production LLM systems will use some form of intelligent scheduling, according to Gartner. The old way-static batching-is already obsolete. Cloud providers like AWS, Google, and Microsoft have baked continuous batching into their managed services. Enterprises are adopting it fast because the cost savings are massive.

A single A100 GPU running static batching might handle 200 tokens per second. With continuous batching and smart scheduling? It hits 800-1,000 tokens per second. That’s a 4x improvement. For companies serving millions of requests daily, that means cutting cloud bills by 60-70%.

It’s not magic. It’s math. And it’s happening right now. The difference between a good LLM deployment and a great one isn’t the model. It’s the scheduler.
